Epson TM-U590 Technical Reference Guide

18
Printing Specifications
cps: characters per inch
cpl: characters per line
Character Specifications
Printing method Serial impact dot matrix
Head wire configuration 9-pin vertical line, 0.353 mm {1/72"} wire pitch
Head wire diameter 0.29 mm {0.01"}
Printing direction Bidirectional, minimum distance printing
Printing speed Font A 233 cps
Font B 311 cps
Font C 233 cps
Characters per line Font A 66 cpl
Font B 88 cpl
Font C 66 cpl
Character intervals Font A 2.03 mm
Font B 1.52 mm
Font C 2.03 mm
Printing speed may be slower, depending on the such items as the data transmission
speed.
Number of characters Alphanumeric characters: 95
Extended graphics: 128 × 8 pages (including user-defined page)
International characters: 37
Character structure Font A 9 × 9, 3-dot spacing (in half-dot units)
Font B 7 × 9, 2-dot spacing (in half-dot units)
Font C 5 × 9, 1-dot spacing (in normal-dot units)
Character size Font A 1.6 × 3.1 mm {0.06 × 0.12"}
Font B 1.3 × 3.1 mm {0.05 × 0.12"}
Font C 1.6 × 3.1 mm {0.06 × 0.12"}

Epson TM-U590 Specifications

General

Color	No
Maximum number of copies	4 copies
Maximum print size	A4 (210 x 297 mm)
Media thickness	0.09 - 0.36 mm
Dimensions (WxDxH)	252 x 266 x 185 mm
Power requirements	24 DVC± 10%
Connectivity technology	Wired
Safety	UL / C-UL / TUV
Certification	VCC # 1, FCC class A, CE
Country of origin	China
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2600 mm
Quantity per pallet	6 pc(s)
Quantity per pallet (UK)	56 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	8 pc(s)
Package depth	333 mm
Package width	322 mm
Package height	253 mm
Package weight	5725 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	266 mm
Width	252 mm
Height	185 mm
