Epson TM-U590 Technical Reference Guide

30
Selecting the BUSY Status
With DIP switch 2-1, you can select conditions for invoking a BUSY state as either of the
following:
•When the receive buffer is full
•When the receive buffer is full or the printer is offline
Printer BUSY condition and status of DIP switch 2-1
*1: When the remaining space in the buffer drops to 16 bytes, the printer status becomes “buffer
full” and it remains “buffer full” until the space in the receive buffer increases to 26 bytes.
In either case above, the printer enters the BUSY state after power is turned on (including
resetting with the interface), and when a self-test is being run.
Printer status
DIP SW 2-1
ON OFF
Offline During the period after power is turned on
(including resetting with the interface) to when
the printer is ready to receive data.
BUSY BUSY
During the self-test. BUSY BUSY
When the cover is open. — BUSY
During paper feed with the FEED button. — BUSY
When an error has occurred. — BUSY
When the receive buffer becomes full.*
1
BUSY BUSY
If DIP switch 2-1 is on, the printer will not become BUSY
• When error has occurred
• When the cover is open
• When paper is fed by the FEED button

Epson TM-U590 Specifications

General

Color	No
Maximum number of copies	4 copies
Maximum print size	A4 (210 x 297 mm)
Media thickness	0.09 - 0.36 mm
Dimensions (WxDxH)	252 x 266 x 185 mm
Power requirements	24 DVC± 10%
Connectivity technology	Wired
Safety	UL / C-UL / TUV
Certification	VCC # 1, FCC class A, CE
Country of origin	China
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2600 mm
Quantity per pallet	6 pc(s)
Quantity per pallet (UK)	56 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	8 pc(s)
Package depth	333 mm
Package width	322 mm
Package height	253 mm
Package weight	5725 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	266 mm
Width	252 mm
Height	185 mm
