Epson TM-U590 Technical Reference Guide

38
ESC/POS Command
ESC/POS is the Epson original printer command system. With ESC/POS commands, you can
directly control all the TM printer functions, but detailed knowledge of printer specifications or
combination of commands is required compared to using a driver.
To use ESC/POS commands, you need to make a nondisclosure cont
ract first and get the
ESC/POS Application Programing Guide. Ask your dealer for details.
The ESC/POS command functions are listed as follows. See the ESC/POS Application
Programing Guide for more details.
ESC/POS command functions
Commands for printing
Print and line feed
Print and eject slip paper
Set slip paper eject length
Set/cancel slip paper reverse eject
Print and feed paper
Print and reverse feed
Print and feed n lines
Print and reverse feed n lines
Set slip paper wait time
Release
Enable/disable operation of feed to the print starting position for slip paper
Print data in page mode
Print and return to standard mode (in page mode)
Commands for line spacing
Set line spacing
Select default line spacing
Commands for print character
Select character code table
Select an international character set
Turn unidirectional printing mode on/off

Epson TM-U590 Specifications

General

Color	No
Maximum number of copies	4 copies
Maximum print size	A4 (210 x 297 mm)
Media thickness	0.09 - 0.36 mm
Dimensions (WxDxH)	252 x 266 x 185 mm
Power requirements	24 DVC± 10%
Connectivity technology	Wired
Safety	UL / C-UL / TUV
Certification	VCC # 1, FCC class A, CE
Country of origin	China
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2600 mm
Quantity per pallet	6 pc(s)
Quantity per pallet (UK)	56 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	8 pc(s)
Package depth	333 mm
Package width	322 mm
Package height	253 mm
Package weight	5725 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	266 mm
Width	252 mm
Height	185 mm
