Epson TM-U590 Technical Reference Guide

Chapter 2 Setup
25
2
Setup
This chapter describes setup and installation of the product and peripherals.
Flow of Setup
This chapter consists of the following sections along with the setup flow of the product and
peripherals.
Installing the Printer
Important Notes on Installation
•The printer must be installed horizontally.
•Do not place the printer in dusty locations.
•Do not apply excessive pressure to the printer.
•Do not put any liquids or drinks such as coffee on the printer case.
1. Installing the Printer (page 25)
5. Connecting the Cash Drawer (page 35)
4. Connecting the Power Supply Unit (PS-180) (page 34)
3. Connecting the Printer to the Host Computer (page 31)
2. Setting the DIP Switches (page 26)

Epson TM-U590 Specifications

General

Color	No
Maximum number of copies	4 copies
Maximum print size	A4 (210 x 297 mm)
Media thickness	0.09 - 0.36 mm
Dimensions (WxDxH)	252 x 266 x 185 mm
Power requirements	24 DVC± 10%
Connectivity technology	Wired
Safety	UL / C-UL / TUV
Certification	VCC # 1, FCC class A, CE
Country of origin	China
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2600 mm
Quantity per pallet	6 pc(s)
Quantity per pallet (UK)	56 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	8 pc(s)
Package depth	333 mm
Package width	322 mm
Package height	253 mm
Package weight	5725 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	266 mm
Width	252 mm
Height	185 mm
