Epson TM-U590 Technical Reference Guide

24
Option Specifications
Power Supply Unit (PS-180)
Material
No specific brominated flame retardants, such as PBBE and PBB, are used in this product.
AC cable selection
Select an AC cable that satisfies the following conditions.
•Safety standard product
•Plug with PE terminal
Ground connections
Be sure to ground for safety.
Electric
characteristics
Input conditions input voltage (rating): 90 to 264VAC
(100VAC -10% to 230VAC +15%)
Frequency (rating): 50/60 Hz ± 3 Hz
Power consumption (rating): 100VA
Output conditions Output voltage (rating): 24VDC ± 5%
Output current (rating): 2.0A
Output electric power (rating): 48VA
Output peak current: 4.5A
Case specifications Dimensions
(H × W × D)
68 × 136 × 32 mm {2.68 × 5.35 × 1.26"}
(excluding projections)
Weight Approx. 0.4 kg {14.11 oz} (excluding the AC cable)
Color Black (matte)
136
68
32
[Unit: mm]

Epson TM-U590 Specifications

General

Color	No
Maximum number of copies	4 copies
Maximum print size	A4 (210 x 297 mm)
Media thickness	0.09 - 0.36 mm
Dimensions (WxDxH)	252 x 266 x 185 mm
Power requirements	24 DVC± 10%
Connectivity technology	Wired
Safety	UL / C-UL / TUV
Certification	VCC # 1, FCC class A, CE
Country of origin	China
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2600 mm
Quantity per pallet	6 pc(s)
Quantity per pallet (UK)	56 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	8 pc(s)
Package depth	333 mm
Package width	322 mm
Package height	253 mm
Package weight	5725 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	266 mm
Width	252 mm
Height	185 mm
