Epson TM-U590 Technical Reference Guide

Chapter 2 Setup
31
2
Connecting the Printer to the Host Computer
For Serial Interface
Serial interface connection diagram
When this printer is connected to a host computer by the serial interface, three connection forms
are possible:
•Stand alone
• Pass-through connection
•Y connection
Stand alone
This printer is connected to the host computer directly via the serial port. When a customer
display (DM-D) is to be connected, connect it to the host computer via the serial port.
Pass-through connection
This printer is connected to the host computer over the serial interface via a customer display
(DM-D).
• Be sure to install the driver before connecting the printer to the host computer.
• The printer uses the modular connectors specifically designed for the cash drawer. Do
not connect these connectors to an ordinary telephone line.
P
O
W
E
R
E
R
R
O
R
R
E
L
E
A
S
E
S
L
I
P
F
O
R
W
A
R
D
FO
R
W
A
RD
R
E
V
E
R
S
E
RE
V
E
R
S
E
RELEA
SE
R
ELEASE
EPSON
TM-U590
DM-D
Serial cable
Serial cable Modular cable
Cash drawer
P
O
W
E
R
E
R
R
O
R
R
E
L
E
A
S
E
S
L
I
P
F
O
R
W
A
R
D
FO
R
WA
R
D
R
E
V
E
R
S
E
RE
V
E
RS
E
RELEASE
R
ELEA
SE
EPSON
DM-D
TM-U590
Serial cable Serial cable
Modular cable
Cash drawer

Epson TM-U590 Specifications

General

Color	No
Maximum number of copies	4 copies
Maximum print size	A4 (210 x 297 mm)
Media thickness	0.09 - 0.36 mm
Dimensions (WxDxH)	252 x 266 x 185 mm
Power requirements	24 DVC± 10%
Connectivity technology	Wired
Safety	UL / C-UL / TUV
Certification	VCC # 1, FCC class A, CE
Country of origin	China
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2600 mm
Quantity per pallet	6 pc(s)
Quantity per pallet (UK)	56 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	8 pc(s)
Package depth	333 mm
Package width	322 mm
Package height	253 mm
Package weight	5725 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	266 mm
Width	252 mm
Height	185 mm
