3-20 Setup Rev. D
Note:
Msw 2-3:
The memory switch Msw 2-3 affects the Simplified Chinese model only.
Note:
Msw 8-5:
When Off is selected, a bit of the "roll paper end sensor" in each status that is transmitted from the printer
is changed every time the roll paper cover is open or closed. When On is selected, a bit of the "roll paper
cover open / close" in each status that is transmitted from the printer is changed every time the roll paper
cover is open or closed. When you replace a TM-U210 with a TM-U220, you should adjust the Msw 8-5
to Off.
Msw 8-8:
When Off is selected, a bit of the "automatic recoverable error" in each status that is transmitted from the
printer is changed every time the roll paper cover is open. When On is selected, a bit of the "mechanical
error" in each status that is transmitted from the printer is changed every time the roll paper cover is open.
The setting of Msw 8-5 and 8-8 can be set by “Memory switch setup mode.“ See “Memory Switch Setup
Mode” on page 3-21.
Memory Switch 2
SW Function On Off
1 Reserved - Fixed to Off
2 Reserved - Fixed to Off
3 Selection of the character code system of
the Simplified Chinese
GB2312 GB18030
4 ~ 8 Reserved - Fixed to Off
Memory Switch 8
SW Function On Off
1 ~ 4 Reserved - Fixed to Off
5 Selection of the cover open status Cover open Paper end
6Reserved - Fixed to Off
7 Condition to release the BUSY in the
receive buffer
Remaining 138 bytes Remaining 256 bytes
8 Printer cover open during operation Errors that can possibly
recover
Errors that automatically
recover
Customize value
Function Selectable value
Roll paper width 57.5 mm 69.5 mm
76 mm (default value) --
