VT6L Maintenance 18. Controller Unit
136 VT series Maintenance Manual Rev.2
Controller Unit
Installation
S
tandard
C
leanroom
(1)
Connect
the following connectors to
the
Controller Unit.
A: Power cable connector
B: Signal cable connector
C: LED connectors × 2
C
A
B
C
(2)
Push
the Controller Unit into the base.
Insert the
Controller Unit while moving it
to the right (see the
picture).
Then, gently move the plate of the
Controller Unit
to the
left and let the
thermal conductive sheet
contacts with the
wall inside
the base.
Move it to the right to insert
Push to the left gently
Push
the Controller Unit while fixing the
cables from
the Joint #1 motor at the base
opening. Be careful not to push
the
cables
to the back of the base.

NOTE

NOTE
