5. When the cleaning cycle is finished, you can check to see if the nozzles are clean; click Print Nozzle
Check Pattern and click Print.
6. Check the printed pattern to see if there are gaps in the lines.
Print head is clean
Print head needs cleaning
• If there are no gaps, click Finish.
• If there are gaps or the pattern is faint, click Clean to clean the print head again.
If you don’t see any improvement after cleaning the print head up to 4 times, turn off the product and wait
at least 6 hours. Then check the print head nozzles and try cleaning the print head again, if necessary. If
quality still does not improve, contact Epson.
Parent topic: Print Head Cleaning
Related tasks
Cleaning the Print Head Using the Product Control Panel
Flushing the Ink Tubes
You can run Power Ink Flushing to clear the print head nozzles if necessary.
Note: Power Ink Flushing may shorten the maintenance box service life.
1. Turn off the product.
2. Press and hold the back button while pressing the power button to turn the product back on.
You see a message asking if you want to run Power Ink Flushing.
306

Epson WF-R5690 Specifications

General

Max Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Scanner Type	Flatbed, ADF
Max Scan Resolution	1200 x 2400 dpi
ADF Capacity	50 sheets
Fax	Yes
Print Technology	PrecisionCore Inkjet
Paper Capacity	250 sheets
Duty Cycle	Up to 45, 000 pages per month
Paper Sizes	A4, A5, A6, Legal, Letter
Mobile Printing	Apple AirPrint, Google Cloud Print
Display	4.3" Color touchscreen
Weight	12.5 kg
Print Speed	ISO: Up to 20 ppm (black/color)
