2011/03/02
Revision: 1 Page: 39
5.1.14 Set absolute vertical print position ESC (V nL nH mL mH
ESC (V nL nH mL mH Ver 1.00
[Name] Set absolute vertical print position [Operation]
[Format] 1BH, 28H, 56H, nL, nH, mL, mH
[Range of Definition] nL=02H, nH=00H
(Vertical position set) = (mL + mH x 256) x (units set)
[Function] 1) The printing position in the Y direction is set to a position spaced in the positive direction
by (256 x mH + mL) x (the set absolute vertical position unit) x 25.4 mm from the origin
upon the Y axis of the position management coordinate system.
2) If this command sets the printing position in the Y direction to a non-printable area, then the
paper is ejected. The position management coordinate system is set to the next page. In
addition, the printing position in the Y direction is reset to the origin on the Y axis of the
new position management coordinate system.
3) Settings made in a negative direction are ignored.
[Initial State] -
[Related Commands]
[Setting] Commands whose settings are affected by this command.
None
[Setting] Commands that change the effects of this command.
None
[Operation] Commands whose functionality is affected by this command.
None
[Operation] Commands that change the effects of this command.
The absolute vertical position unit value is set by the ESC( U commands.
The range of unprintable areas are set by the ESC( c, ESC N and ESC O commands.
The relative vertical position setting value, the non-printable area and the printing position in the
Y direction are reset to their initial states by the ESC @ and ESC (G commands.
