Epson WorkForce 633 - Select Color ESC

2011/03/02
Revision: 1 Page: 46
5.1.21 Select color ESC (r nL nH m n
ESC (r nL nH m n Ver 1.00
[Name] Select color [Setting]
[Format] 1BH, 28H, 72H, nL, nH, m, n
[Range of Definition] nL=02H, nH=00H
m=00H, 01H
n=00H, 01H, 02H, 04H
[Function] 1) The print color is selected according to the values of m and n.
m N Print color
00H 00H Black
00H 01H Magenta
00H 02H Cyan
00H 04H Yellow
2) If either m or n has a value other than those above, this command is ignored.
3) This command is only effective in graphics mode.
[Initial State] Black is selected.
[Related Commands]
[Setting] Commands whose settings are affected by this command.
None
[Setting] Commands that change the effects of this command.
The ESC @ command selects black.
[Operation] Commands whose functionality is affected by this command.
None
[Operation] Commands that change the effects of this command.
The ESC (G command puts the printer in graphics mode.
