Epson WorkForce AL-M200DN User Manual

5. In the IP Address Mode field, select the DHCP/AutoIP option.
6. Click the Apply button.
Assigning an IP Address (for IPv4 Mode)
Note:
❏ When you assign an IP address manually in IPv6 mode, use EpsonNet Config. To display EpsonNet
Config, use the link local address. To check a link local address, see “Printing and Checking the
System Settings Page” on page 34.
❏ Assigning an IP address is considered as an advanced function and is normally done by a system
administrator.
❏ Depending on the address class, the range of the IP address assigned may be different. On Class A, for
example, an IP address in the range from 0.0.0.0 to 127.255.255.255 will be assigned. For
assignment of IP addresses, contact your system administrator.
You can assign the IP address by using the operator panel or the Printer Setting Utility.
Using the Operator Panel
1. Turn on the printer.
Ensure that the LCD panel shows Ready to Print.
2. On the operator panel, press the (Menu) button.
3. Select Admin Menu, and then press the
button.
4. Select Network, and then press the
button.
5. Select TCP/IP, and then press the
button.
6. Select IPv4, and then press the
button.
7. Select Get IP Address, and then press the
button.
8. Select Panel, and then press the
button.
9. Press the
(Back) button, and then ensure that Get IP Address is selected.
AL-M200 Series User’s Guide
Printer Connection and Software Installation 31

Epson WorkForce AL-M200DN Specifications

General

Multi-Purpose tray	Yes
Total input capacity	250 sheets
Total output capacity	125 sheets
Total number of input trays	1
Multi-Purpose tray input capacity	10 sheets
Printing colors	Black
Country of origin	China
Maximum duty cycle	30000 pages per month
Number of print cartridges	-
Page description languages	PCL 6, PostScript 3
Color	No
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Safety	IEC60950-1, EN60950-1, IEC60825-1, EN60825-1
Quantity per pack	1 pc(s)
Networking features	Fast Ethernet
Networking standards	IEEE 802.3, IEEE 802.3u
Supported media weight(s)	60 - 163 g/m²
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	Port 9100, WSD, NDS Printserver
Sound power level (standby)	54.4 dB
Sound pressure level (quiet mode)	24.8 dB
Envelopes sizes	DL
Maximum print size	210 x 297 mm
Paper tray media types	Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
ISO C-series sizes (C0...C9)	C5
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet, USB 1.1, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	50 W
Power consumption (printing)	450 W
Sustainability certificates	ENERGY STAR
Display	LCD
Certification	EN55022, EN61000-3-2, EN61000-3-3
Product color	White
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	15 - 80 %
Operating relative humidity (H-H)	10 - 85 %
Bundled software	Epson Status Monitor
Pallet width	800 mm
Pallet height	2130 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	12 pc(s)
Quantity per pallet (UK)	24 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	4 pc(s)
Package depth	477 mm
Package width	442 mm
Package height	330 mm
Package weight	8320 g

Weight and Dimensions

Dimensions (WxDxH)	385 x 355.6 x 225 mm
