Epson WorkForce Pro WF-M5690DWF

To Next Page

To Previous Page

1. Open the ADF cover.

2. Use a

so,

dry, clean cloth to clean the roller and the interior of the ADF.

User's Guide

Improving Print and Scan Quality

120
