A
Document cover Blocks external light while scanning.
B
Scanner glass Scans placed originals.
C
Control panel Operates the printer.
D
External interface USB port Connects memory devices.
E
Print head Fires ink.
F
Front cover Open when replacing an ink cartridge and removing
jammed paper inside the printer.
A
Rear cover Pull out when replacing the maintenance box and
removing jammed paper.
B
AC inlet Connects the power cord.
User's Guide
Printer Basics
18
