9 FAULT CODES
0459 287 601
- 29 -
© ESAB AB 2020
9 FAULT CODES
9.1 General
Fault codes are used to indicate that a fault has occurred in the equipment. They are shown
in the display in the form of a symbol as follows:
Fault codes are updated every three seconds. The upper numeral in the
symbol is the number of the particular fault code. The lower figure indicates
where the fault is.
The above symbol shows that the control panel (0) has lost contact with the power unit.
If several faults have been detected, only the code for the last fault to occur will be displayed.
Press any of the function keys in order to clear the symbol from the display.
Symbols may be steady or flashing, depending on the type of fault.
Flashing symbols are highlighted with “o” in the list of fault codes.
9.2 List of fault codes
0 = control panel 3 = wire feed unit
1 = cooling unit 4 = remote control
2 = power source
Unit Power supply 1* Power supply 2* Power supply 3*
Cooling unit +24V
Control panel +3V
Power unit +15V -15V +24V
Wire feed unit
Wire feed unit L
+15V
+15V
+ 20V
+ 60V
Remote control +12V +10V
9.3 Fault code descriptions
Below are described event codes at which the user himself can take corrective action. If any
other code is shown, send for a service technician.
1
Program memory error, (EPROM)
There is an error in the program memory.
This error does not disable any functions.
1. Restart.
2. If the error persists, send for a service technician.
2
Microprocessor RAM error
The microprocessor is unable to read/write from/to a certain memory position in its
internal memory.
This error does not disable any functions.
