ESAB Aristo U6 - Introduction to Aristo U6 Control Panel; Initial Setup and Language Selection

1 INTRODUCTION
0459 287 601
- 4 -
© ESAB AB 2020
1 INTRODUCTION
This manual describes operation of the U6 control panel.
For safety and general information on operation, see the wire feed unit and power source
operating instructions.
Instruction manuals in other languages can be downloaded from the Internet:
manuals.esab.com
1.1 Do this first
This menu appears on the display the first time that you start the power unit.
4 - STROK CRAT FILL HOT START NEXT
When delivered, the control panel and display are set to English. There are 14 languages
stored in the control panel: change to the one that you want as follows.
Press MENU to reach the first SELECT MENU.
MIG / MAG
ER70S
CO2
19,2 VOLT
SELECT MENU
0,8 MM

5.0 M/MIN
PROCESS SETTING CONFIG MEMORY
Press CONFIG to reach the CONFIGURE MENU.
