ESAB Aristo U6 - Settings Menu Parameters; Configure Menu Options; Memory Menu Functions

2 MENUS
0459 287 601
- 9 -
© ESAB AB 2020
Settings menu
- - SETTINGS MENU 1 / 2 - -
INDUCTANCE
GAS PREFLOW
HOTSTART TIME
CRATR FILL T.
80%
0.1 s
1.5 s
1.0 s
↓ MAIN MENU — +
Use the SETTINGS MENU to set welding parameters, such as gas pre-flow, hot start time,
crater fill time etc.
Configure menu
- CONFIGURE MENU 1 / 1 -
LANGUAGE
DIMENSIONS
PANEL ENABLE
TRIGGER DATA
ENGLISH
METRIC
ON
OFF
↓ MAIN MENU NEXT
Use the CONFIGURE MENU to change the language, measurements units etc.
Memory menu
1

EMPTY

STORE RECALL DELETE NEXT
Use the MEMORY MENU to store, recall and/or erase various stored welding data settings.
There are ten storage positions for welding data.
