ESAB AristoMig U400 - Exchange Circuit Boards

Edition 050614
-- 5 2 --
clhr1fe2com
Exchange circuit boards
Exchange circuit boards are repaired and tested circuit boards. We offer those boards to a
lower price than new circuit boards. When an exchange circuit board is ordered, the defect
board must be sent back to ESAB. Use only antistatic packaging materials for the
circuit boa rd. If we do not receive the defect board, or if it is not packed in antistatic
packaging, the price for the exchange board will be 30 to 50% higher than the normal price.
Some boards must have a machine ID, for this you need the Esat service kit. In order to
make the service of the machines easy, we offer the boards with individual ordering
numbers, where machine-- ID is needed (plug and play). Machine ID is needed for the
boards in the control panels (MMC module) and the wire feed units.
There are three price levels for the circuit boards, level 1. is the cheapest:
1. Exchange board without machine ID
2. New circuit board without ID
3. Exchange board with machine ID
During the warranty period we only accept the warranty costs for circuit boards without
machine ID.
All circuit boards in the spare parts list are new circuit boards. Below is a list of the
exchange boards for the AristoArc 400, AristoTig 400, AristoMig 400 and the control panels.
Complete exchang e co n trol panels with machine ID
Panel Ordering no. Panel Ordering no. Panel Ordering no.
A2 E458 535 881 T4 E458 535 883 M2 E458 535 882
A4 E458 535 888 T6 E458 535 885 MA4 E458 535 884
U6 E458 535 890 MA6 E458 535 886
Exchange circuit boards for control panels
Panel ID Ordering no. Panel ID Ordering no. Panel ID Ordering no.
A2 no E486 819 887 T4 no E486 819 880 M2 no E486 819 887
A2 yes E486 819 881 T4 yes E486 819 883 M2 yes E486 819 882
A4 no E486 819 880 T6 no E486 819 880 MA4 no E486 819 880
A4 yes E486 819 888 T6 yes E486 819 885 MA4 yes E486 819 884
U6 no E486 819 880 MA6 no E486 819 880
U6 yes E486 819 890 MA6 yes E486 819 886
Exchange circuit boards for power sources
Product PCB ID Ordering no. Notes
AristoArc/Tig/Mig 15AP1 -- E486 739 880
AristoArc/Tig/Mig 20AP1* yes
yes
E458 842 880
E458 842 882
*The defect circuit board, 20AP1, must be
returned complete with its screening box
Use E458 842 882
f
rom ser.no.347--xxx--x
x
x
x
AristoArc/Tig/Mig 20AP2 -- E486 855 880
U
s
e
E
4
5
8
8
4
2
8
8
2
f
r
o
m
s
e
r
.
n
o
.
3
4
7
x
x
x
x
x
x
x
