Edition 050614
-- 9 --
cu20d1
AristoArc 400
Mains voltage 400 V, ±10%, 3∼ 50 Hz
Primary current I
max
38 A
No--load power in energy--saving mode 6.5 min. after
welding
50 W
Setting range 16 A -- 400 A
Maximum permissible load at
35% duty cycle
60 % duty cycle
100 % duty cycle
400 A / 36 V
320 A / 33 V
250 A / 30 V
Power factor at maximum current 0.65
Efficiency at maximum current 85%
Open --circuit voltage 78 -- 90 V
Temperature range --10 till + 40˚C
Dimensions, l x b x h 625 x 294 x 492 mm
Continual A--weighted sound pressure <70 db
Weight 45 kg
Insulation class H
Enclosure class IP 23
Application class
Duty cycle
The duty cycle refers to the time as a percentage of a ten--minute period that you can weld at a cer-
tain load without overloading.
Enclosure class
The IP code indicates the enclosure class, i. e. the degree of protection against penetration by solid
objects or water. Equipment marked IP23 is designed for indoor and outdoor use.
Application class
The symbol indicates that the power source is designed for use in areas with increased
electrical hazard.
