3 TECHNICAL DATA
0463 479 001
- 14 -
© ESAB AB 2017
EMP235ic
Permissible load at SMAW - Stick
100% duty cycle 130A/25.2V 65A/22.6V
60% duty cycle 170A/26.8V 80A/23.2V
40% duty cycle – 85A/23.4V
25% duty cycle 210A/28.4V –
Setting range (DC) 16 A/20.6 V – 210A/28.4V 16 A/20.6 V – 130A/25.2V
Open circuit voltage (OCV)
VRD deactivated 68V 68V
VRD activated 35V 35V
Efficiency 85% 84%
Power factor 0.98 0.99
Wire feed speed 80-700in./min
(2.0-17.89m/min)
80-700in./min
(2.0-17.89m/min)
Wire diameter
Mild steel solid wire 0.023–0.045in. (0.6–1.2mm) 0.023–0.045in. (0.6–1.2mm)
Stainless steel solid wire 0.030–0.045in. (0.8–1.2mm) 0.030–0.045in. (0.8–1.2mm)
Flux cored wire 0.030-0.052in. (0.8-1.3mm) 0.030-0.052in. (0.8-1.3mm)
Aluminum 0.030–0.045in. (0.8–1.2mm) 0.030–0.045in. (0.8–1.2mm)
Bobbin size Ø 4–12in. (100–300mm) Ø 4–12in. (100–300mm)
Dimensions l×w×h 23×9×16in.
(548×229×406mm)
23×9×16in.
(548×229×406mm)
Weight 53lb (24kg) 53lb (24kg)
Operating temperature 14to104°F (-10to+40°C) 14to104°F (-10to+40°C)
Enclosure class IP23S IP23S
Application classification
EM235ic
Voltage 230 V, 1 ~ 50/60 Hz 120 V, 1 ~ 50/60 Hz
Primary current
I
max.
GMAW - MIG
32.1A
Breaker 20A: 28.6A
Breaker 15A: 20.3A
I
eff.
GMAW - MIG
20.31A
Breaker 15A: 14.6A
Breaker 20A: 18.0A
Permissible load at GMAW - MIG
100% duty cycle 160A/22.0V Breaker 15A: 75A/17.75V
Breaker 20A: 90A/18.5V
60% duty cycle 200A/24.0V Breaker 15A: 90A/18.5V
Breaker 20A: 110A/19.5V
40% duty cycle 235A/25.75V Breaker 15A: 100A/19V
20% duty cycle – Breaker 20 A: 130 A/20.5 V
