ESAB EMP235ic - Operation Guide

5 OPERATION
0463 479 001
- 18 -
© ESAB AB 2017
120 – 230V, 1 ~ 50/60Hz
Maximum recommended extension cord length 50ft (15m) 25ft (8m)
Minimum recommended grounding conductor size 10AWG
(5.3mm
2
)
12AWG
(4mm
2
)
Supply from power generators
The power source can be supplied from different types of generators. However, some
generators may not provide sufficient power for the welding power source to operate
correctly. Generators with Automatic Voltage Regulation (AVR) or with equivalent or better
type of regulation, with 10kW rated power, are recommended.
4.3.2 Connecting the power source to input supply
Use one of the supplied adapters to connect the power source to mains.
5 OPERATION
General safety regulations for handling the equipment can be found in the "SAFETY
PRECAUTIONS" chapter of this manual. Read it through before you start using the
equipment!
NOTE!
When moving the equipment, use the intended handle. Never pull on the cables.
