4 INSTALLATION
0463 479 001
- 15 -
© ESAB AB 2017
EM235ic
Setting range (DC) 15A/14.75V–250A/30.0
V
15A/14.75V–130A/20.5
V
Open circuit voltage (OCV)
VRD deactivated 68V 68V
VRD activated 35V 35V
Efficiency 84% 84%
Power factor 0.98 0.99
Wire feed speed 60-700in./min
(1.5-17.89m/min)
60-700in./min
(1.5-17.89m/min)
Wire diameter
Mild steel solid wire 0.023–0.045in. (0.6–1.2mm) 0.023–0.045in. (0.6–1.2mm)
Stainless steel solid wire 0.030–0.045in. (0.8–1.2mm) 0.030–0.045in. (0.8–1.2mm)
Flux cored wire 0.030-0.052in. (0.8-1.3mm) 0.030-0.052in. (0.8-1.3mm)
Aluminum 0.030–0.045in. (0.8–1.2mm) 0.030–0.045in. (0.8–1.2mm)
Bobbin size Ø 4–12in. (100–300mm) Ø 4–12in. (100–300mm)
Dimensions l×w×h 23×9×16in.
(548×229×406mm)
23×9×16in.
(548×229×406mm)
Weight 53lb (24kg) 53lb (24kg)
Operating temperature 14 to 104°F (-10to+40°C) 14 to 104°F (-10to+40°C)
Enclosure class IP23S IP23S
Application classification
Duty cycle
The duty cycle refers to the time as a percentage of a ten-minute period that you can weld at
a certain current without overheating. The duty cycle is valid for 104°F / 40°C.
For more information, see section "Duty cycle" in the OPERATION chapter.
Enclosure class
The IP code indicates the enclosure class, i.e. the degree of protection against penetration
by solid objects or water.
Equipment marked IP 23S is intended for indoor and outdoor use; however, should not be
operated in precipitation.
Application class
The symbol indicates that the power source is designed for use in areas with increased
electrical hazard.
4 INSTALLATION
The installation must be carried out by a professional.
CAUTION!
This product is intended for industrial use. In a domestic environment, this
product may cause radio interference. It is the user's responsibility to take
adequate precautions.
