6.6 Mounting Additional Roof Supports
1. Attach the roof support to the adapter by means of the click connection.
2. Click the adapter (including roof support) onto the base prole.
3. Position the adapter at a distance of 420mm (=2 bricks in length) from the high base element.
4. Repeat this operation for the remaining segments.
10
Rev. 08.08.23 MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS
2.
CLICK !
3.
420 mm =
2 bricks
420 mm
1.
