End clamp + grounding clamp
Earth rail
Multi-core cable (6mm
2
)
Module clamp + equipotential
27
Rev. 08.08.23 MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS
7.3.2 Equipotential bonding and earth rail
Grounding bracket (optional)
Optional for wind deectors at the rear in the last row
and/or for ballast containers.
