Table range panel dimensions
Edge zone
The distance from the solar panels to the edge of the roof must be approximately 1/5 of the height of the building with a minimum
distance of 30 cm, due to the very turbulent wind currents in this zone. No solar panels must be installed in this zone, either in whole or in
part. The edge zone to be maintained is derived from the Esdec calculator.
Ballast
If your roof is higher than 20 metres, we recommend that you consult with your supplier to help determine the correct ballast. Use stones
or gravel as ballast. Consult the project plan.
Standards, regulations and rules
When installing the mounting system, it is important to follow the installation manual and related standards to prevent accidents. In
particular, observe the following standards, regulations and rules:
• Building Regulations 2010 applicable document see: www.legislation.gov.uk
• EN 1990 Basis of structural design
• EN 1991-1-3 General loads – snowload
• EN 1991-1-4 General loads – wind pressure
• NEN 7250: 2021 Structural aspects of power systems
• HD-IEC 60363 series Electrical installations for low voltage
• EN-IEC 62305 Series Lightning protection
• Health and Safety at Work Deregulation Act 2015; see: www.legislation.gov.uk
• Health and Safety in Roof work HSE regulation; see: www.hse.gov.uk
Removal and disassembly
Dispose of the product in accordance with local laws and regulations. At the end of the service life, all materials are recyclable.
The aluminium base proles are attached to the bases by means of a click system. Use combination pliers to disassemble the base
prole.
Warranty
Warranty according to the Esdec BV warranty terms. These can be found on the website www.esdec.com.
Liability
The manufacturer accepts no liability for damage or injury caused by failure to comply (strictly) with the safety guidelines and instructions
in this manual, or by negligence during installation of the product and the accessories listed in this document.
02
Rev. 08.08.23 MANUAL FOR FLATFIX FUSION MOUNTING SYSTEM FOR FLAT ROOFS
Panel length range Panel width range
