Function 3: Extension programming IP Series Installation Manual
F.8
Paired IP Feature Phone/analog phone operation
For someone wishing to have an IP Feature Phone in his office and a cordless phone for roaming
the building:
1. Create a call forward key on the IP Feature Phone to forward to the cordless phone.
2. Program the call forward busy/no answer for the cordless station to the IP Feature Phone’s
mailbox. The user will then have all of his messages in one location (however, he/she can re-
trieve them from either phone).
Overhead paging interface
You can connect a dry-contact overhead paging device to the system through the OH Paging inter-
face on the front of the IP PBX. The overhead paging port’s access is fixed as extension 199 for
programming purposes. The user can access it by:
(a.) Dialing 1 9 9
or
(b.) Programming 199 as a programmable key
and /or including 199 in one or more page zones.
Note: DTMF can be transmitted to the overhead paging port after access, allowing for zone over-
head paging, if the paging unit supports zone paging.
1. 2.
Ext. Type Name CO CF day Cf night Pg zn
0 Operator X100 X100
100 FP Jane 9 MB100 X105 1,2
199
Each programming step for overhead paging is defined as follows:
1. Extension number — Enter 1 9 9 during extension programming.
2. Extension page zone assignment — List the page zones (1, 2, 3) that are to include, also, the
overhead paging port. (All page)
Example: Here is a portion of a completed Programming Worksheet (Appendix II) for
extensions. The paging port, extension 199, has been added to page zone 1.
The user then can access only the overhead pager by dialing 1 9 9 or can
page through both the overhead pager and all phones listed in page zone 1
by pressing PAGE (#) and 1 on his/her phone.
1.
2.
Ext. Type Name CO Pg zn
100 IP PHONE JANE 9 1,2
199 1
Dry contact control
The manner in which the dry contact pair is pinned out at the RJ-45 connector sets the pair as either
normally open (sending a page to the port will close the contacts) or normally closed (sending a
page to the port will open the contacts). See the “Hardware installation” section (page B.7).
