2.1 General Information
The system setup and installation section is intended to be as thorough as possible. If in-
doubt at any point, please contact EST Analytical toll free at (800) 283-3510. If
installation is not directed or performed by EST Analytical personnel, the operator must
be thoroughly familiar with setup and installation sections of this manual.
NOTE: Failure to follow the installation instructions as set forth could result in
damage to the product and nullify the warranty.
2.2 Work Space Requirements
The Centurion foot print is 24.5”W (62.2 cm) x 27”D (68.6 cm) x 25” H (63.5 cm).
NOTE: Allow for added space on all sides of the instrument for proper ventilation.
2.3 Power Requirements
Voltage:
115/230 VAC (+/- 10%)
50/60 Hz
8.0/5.0 Amps
15/20A circuit breaker
2.4 Unpacking the Centurion
Figure 2a: Shipping Container
The Centurion is packaged in one Carton containing all components necessary for
instrument installation and operation.
NOTE: Retain all shipping material.
