4.10 Fuse Replacement
All of the printed circuit boards in the Centurion have fuses. If any of the fuses need
replacement, power down the Centurion, remove the side panel, and replace the fuse.
PWMTCBoardESTPartNumbers:Z1838FP007andZ1838FP008
FuseNumber Description/Type
F1 2A250VSLOBLOTR5TYPE
F2‐F13,F17 6.3A250VSLOBLOTR5TYPE
F14‐F16 2A250VSLOBLOTR5TYPE
F18 10A250VSLOBLO3AGTYPE
DIOBoardESTPartNumber:Z1838FP006
FuseNumber Description/Type
F1‐F25 1A250VSLOBLOTR5TY
PE
F26 10A250VSLOBLOTR5TYPE
IOBoardESTPartNumber:Z1838FP002
FuseNumber Description/Type
F1 5A250VSLOBLOTR5TYPE
F2‐F3 6.3A250VSLOBLOTR5TYPE
IOBoardESTPartNumber:Z1838FP004
FuseNumber Description/Type
F1 2A250VSLOBLOTR5TY
PE
F2 6.3A250VSL O BLOTR5TYPE
4.11 Spare Parts
For a complete list of spare parts visit http://www.estanalytical.com/shop
