NOTE: The Encon Evolution needs to be lifted from the base of the instrument.
WARNING: The Encon Evolution needs enough space on all sides of the
instrument to ensure proper cooling of instrument components AND to ensure
that the power cord can be easily disconnected.
AVERTISSEMENT: Le Encon Evolution a besoin de suffisamment d'espace sur
tous les côtés de l'appareil pour assurer le bon refroidissement des composants
de l'instrument et de veiller à ce que le cordon d'alimentation peut être
facilement déconnecté .
NOTE: Please retain all shipping material.
2.5 System Setup
Please refer to Figure 2b for a view of the back panel of the Encon Evolution.
Figure 2b: View of the Encon Evolution’s back panel
2.5.1 Interface Connection
Install the supplied interface cable between the Encon Evolution and Gas
Chromatograph. Call EST at (800) 283-3510 or (513) 642-0100 if you have any questions
about your interface connection.
