4.5 Fuse Replacement
All of the printed circuit boards in the Encon Evolution have fuses. If any of the
fuses need replacement, power down the Encon Evolution, remove the cover, and replace
the fuse.
PWMTCBoardESTPartNumbers:Z1838FP001
FuseNumber Description/Type
F1 2A250VSLOBLOTR5TYPE
F2‐F13,F17 6.3A250VSLOBLOTR5TYPE
F14‐F16 2A250VSLOBLOTR5TYPE
F18 10A250VSLOBLO3AGTYPE
DIOBoardESTPartNumber:Z1838FP003
FuseNumber Description/Type
F1‐F25
 1A250VSLOBLOTR5TYPE
F26 10A250VSLOBLOTR5TYPE
IOBoardESTPartNumber:Z1838FP002
FuseNumber Description/Type
F1 5A250VSLOBLOTR5TYPE
F2‐F3 6.3A250VSLOBLOTR5TYPE
IOBoardESTPartNumber:Z1838FP004
FuseNumber Description/Type
F1 2A250VSLO
BLOTR5TYPE
F2 6.3A250VSLOBLOTR5TYPE
4.6 Spare Parts
For a complete list of spare parts visit http://www.estanalytical.com/shop
