ETAS 2 Configuration Creation
For all signals from the same file, the samples are shifted accord-
ingly. The shifted data is also used for calculated signals. Note that
if you replace the measure file with another one, the defined time
offset remains still the same.
2.2.3 Measure File Comment and other Meta Information
For each measure file used in a configuration, you can display its meta data, e.g.
the file comment and information about when, by whom, and for which project
the file was created.
l "To display comment and other meta information" below
l "To edit comment and other meta information" below
To display comment and other meta information
1. Do one of the following:
In the File Explorer, hover the cursor over a measure file.
The meta data is displayed as a tooltip.
In the File Explorer, select the file and press CTRL+I.
The meta data is displayed in the Information Window. You
can select the content of the table and copy it to the clipboard.
2. If you select another measure file, the meta data is updated auto-
matically in the Information window.
To edit comment and other meta information
1. In the File Explorer right click the measure file and select About
Measure File.
or
Press CTRL+I.
2.
To edit the comment or meta information, click .
You can edit the following fields:
User
Company
Vehicle
Project
Default and User Comment.
The original comment or meta information remains in the measure
file. It can be found if the measure file is opened with an editor tool.
To remove completely the original comment or meta information
and make it anonymous, perform subsequently an export of the
measure data into a new measure file.
MDA V8.5 - User Guide 32
