ETAS 5 Instruments
5 Instruments
The following instruments are supported:
l Oscilloscope
The measurement data are displayed as a graph. This instrument is
recommended for:
Displaying numeric signals, especially periodic signals and signals
with a large amplitude
Getting an overview of one or more signals over the complete time
range of one or more measure files
Comparing two signals over time
l Scatter Plot
The values of two signals are displayed as distribution of data samples
along the orthogonal value axes of the two signals. This instrument is
recommended for:
Detecting a correlation of signals
Getting an overview of the sample distribution
l Table
The measurement data are displayed in a table. This instrument can be
used for:
Displaying non-numeric signals, as well as numeric signals
Inspecting the precise value of a signal for a specific timestamp
l Statistical Data
Statistical properties of numeric signals are displayed, such as the aver-
age, minimum, maximum and standard deviation. This instrument is
recommended for:
Analyzing the statistical properties of numeric signals, which can give
insight into a signal's character and quality
Comparing multiple signals
l Event List
In the event list, you can find certain events for analysis by evaluating a
search condition. This instrument is recommended for:
Finding all timestamps at which the value of a signal changes
Displaying a complete list of EVENT entries from an MDF file, like cal-
ibration activities, pause events, or comments
l GPS Map
The GPS tracks are displayed in a map view. This instrument is recom-
mended for comparing and analyzing geographic data in relation to other
measured signals.
MDA V8.5 - User Guide 74
