ETAS 5 Instruments
l "To reorder strips" below
l "To delete a strip" below
To reorder strips
1. Click on the strip.
A blue bar occurs on the left and right edge of the strip.
2. To move the selected strip, do one of the following:
To move the strip up, press ALT+PAGE UP.
To move the strip down, press ALT+PAGE DOWN.
or
Click on one of those bars and pull it up or down to the desired
position.
The new position of the floating strip is indicated by a small
blue rectangle.
To delete a strip
1. Open the context menu of the strip that you want to delete.
2. Select Delete strip.
5.3.4 Using Axes
You can perform the following actions:
l "To use a Y-axis as X-axis" below
l "To scroll axes" on the next page
l "To zoom axes" on the next page
l "To adjust the axis range or set a favorite axis range" on the next page
To use a Y-axis as X-axis
1. Right-click the Y-axis that you want to use as X-axis.
2. Select Use as X-axis.
The X-axis and Y-axis including their ranges are swapped.
MDA V8.5 - User Guide 97
