ETAS 2 Configuration Creation
2.5 Saving a Signal Selection to a Label File
MDA V8.5 supports to save a selection of signals in a label file format (*.lab).
This allows for example a quick re-creation of an INCA Experiment, by using the
file as a filter in INCA Variable Selection Dialog (for details see the INCA doc-
umentation).
Besides the signal names, a label file can include optionally raster information.
For saving a label file, do the following:
1. Open the Configuration Manager.
2. Right click an object node or select different object nodes for which
you want to export the signals.
3. In the context menu click Create Label File.
4. In the Save As window select the format.
You can choose between V1.0 (only signal names) and V1.1 (signal
names and raster information).
5. Click Save.
To check the export progress, see "To check the export status" on page37 and
"To see the exported file in Windows Explorer" on page37.
MDA V8.5 - User Guide 40
