ETAS 5 Instruments
To move one or more signals to a specific position in the signal
list, drag and drop the selected signals to this position. The new
position is indicated by a blue line. When ordering the signals
manually, the sorting mechanism gets inactive.
To change the number of decimals
1. In the signal list, select one or more signals (except enumerations
or Boolean signals).
2. In the toolbar, click one of the following icons:
To show more decimal places, click .
To show fewer decimal places, click .
The number of decimals is adapted accordingly for all cursor val-
ues in the signal list. The cursor values are also adapted within the
cursor's tooltips.
5.2.3 Zooming
To adapt the value or time axis ranges for the best representation of your data,
MDA provides several zoom possibilities.
You can perform the following actions:
l "To define the zoom area" below
l "To show the full time range" on the next page
l "To zoom to fit signals" on the next page
To define the zoom area
To see how you can zoom, synchronize and scroll in instruments, watch our
video Instruments - Zoom and Synchronization.
1. Press either CTRL and the left mouse button or just the right mouse
button.
2. While keeping the button pressed, move the cursor along a value
axis or along the time axis.
Depending on the mouse movement, the zooming is performed as
follows:
Time zoom (horizontal movement)
Value axis zoom (vertical movement)
The selected zoom area is highlighted.
MDA V8.5 - User Guide 80
