ETAS MDA V8.5 User Manual

ETAS Content
2.5 Saving a Signal Selection to a Label File 40
3 Signal Selection 41
3.1 Defining Display Name in the Application 41
3.2 Defining the View in the Variable Explorer 41
3.3 Sorting and Filtering 42
3.4 Extracting Bits from a Signal 46
3.5 Assigning Signals to Instruments 47
3.6 Displaying Signal Information 49
3.7 Reusing the Signal Name in Other Applications 51
4 Calculated Signals 52
4.1 Defining Calculated Signals 53
4.2 Managing Calculated Signals 55
4.3 Examples for Calculated Signals 57
4.3.1 Extracting Bits or Bit Fields from an Integer 57
4.3.2 Calculating RMS 57
4.3.3 Using Enumeration Signals 58
4.3.4 Applying Calculations to Specific Samples 59
4.4 Calculated Signals Details 63
4.4.1 Data Types 63
4.4.1.1 Data Type Conversion 64
4.4.1.2 Data Type Deduction 64
4.4.2 Formula Syntax 65
4.4.2.1 Literals 65
4.4.2.2 Signals 66
4.4.2.3 Operators 66
4.4.3 Reduction 67
4.4.3.1 Ranges 68
4.4.3.2 Reduction Behaviors 69
4.4.3.3 Reduction Functions 72
5 Instruments 74
5.1 Maintaining Instruments 75
5.2 Oscilloscope 77
5.2.1 Oscilloscope's Toolbar 78
5.2.2 Adjusting the Signal List 78
5.2.3 Zooming 80
MDA V8.5 - User Guide 4
