32 Ion Classic User Manual
Eos Ti Components
Power Button
The power button on the front of the console is used to power up or power down. A separate
hard power switch, located on the rear panel, can be used to disconnect power from the
console’s internal components.
CAUTION:
It is recommended that you safely power down the console via
Displays > Power Off Device before disconnecting power from the console.
CAUTION:
Power cord must be connected using an earth ground
connection.
WARNING: Before servicing your console, you must switch off the power
on the rear panel and disconnect the power cord completely.
Fuse
A fuse is included for additional protection. Fuse ratings can be found on the rear panel of
your console.
CAUTION:
For continued protection against risk of fire, replace only with
same type and rating of fuse.
VORSICHT:
Um weiterhin gegen Brandrisiko geschützt zu sein, ersetzen Sie
die Sicherung nur mit einer Sicherung gleichen Typs und den gleichen
Nennwerten.
ATTENTION:
Pour ne pas compromettre la protection contre les risques
d’incendie, remplacer par un fusible de même type et de mêmes
caractéristiques nominales.
Internal Touchscreens
Eos Ti is designed with three internal touchscreen displays.
The two main touchscreens may be used to display and control show data. They may also
be used as a variety of other virtual controls and displays.
The encoder touchscreen offers additional touch-based controls for encoder parameters.
The touchscreen angle can be adjusted by pushing the button in the center top of the display
and moving the panel up or down.
Touchscreen brightness can be controlled via the
Brightness Settings (on page215)
External Monitors
Windows 7 Ion Classic can support up to 2 monitors, either 2 DVImonitors or 1 Display Port
and 1 DVI.
Display Port can use an active adapter to VGA, DVI, or HDMI. DVI-I can be converted to VGA
with a passive adapter.
Monitor Specifications
Windows 10 consoles
