Eos Configuration Utility 563
Buttons
RPU Face Panel Buttons
This area is for configuring the buttons on the front of a RPU or RVI. Clicking on a button will
open a dialog window for selecting what type of button, macro, hardkey, or none, you wish to
assign.
If hardkey is selected, a list of the various hardkeys on your console will be available to select
from. If macro is selected, a macro number can be entered. Selecting none will assign no
action to the selected button.
{Import} allows you to import a RPU/RVI button configuration file. {Export} allows you to
export a RPU or RVI button configuration file. {Restore Defaults} will restore the factory
defaults for the RPU or RVI buttons.
Face Panel Buttons
This area is for configuring the customizable hardkeys on the Eos Ti, Gio, and Gio @ 5 face
panels.
Clicking on a button will open a dialog window for selecting what type of button, macro,
hardkey, or none, you wish to assign.
If hardkey is selected, a list of the various hardkeys on your console will be available to select
from. If macro is selected, a macro number can be entered. Selecting none will assign no
action to the selected button.
{Import} allows you to import a button configuration file. {Export} allows you to export a
button configuration file. {Restore Defaults} will restore the factory defaults for the buttons
RFR
This screen is used for setting up the Net3 Radio Focus Remote (RFR) to work with Eos.
Note:
These settings need to match between the console and the RFR.
High Frequency Channel
The frequency that the RFR is using. There are 1-12 channels.
Network ID
The Network ID is a separate digital channel on a single high frequency (HF) setting. There are
1-99 IDs available.
