50 Ion Classic User Manual
CAUTION: It is recommended that you safely power down the console via
Displays > Power Off Device before disconnecting power from the console.
CAUTION: Power cord must be connected using an earth ground
connection.
WARNING: Before servicing your console, you must switch off the power
on the rear panel and disconnect the power cord completely.
Fuse
A fuse is included for additional protection. Fuse ratings can be found on the rear panel of
your console.
CAUTION: For continued protection against risk of fire, replace only with
same type and rating of fuse.
VORSICHT: Um weiterhin gegen Brandrisiko geschützt zu sein, ersetzen Sie
die Sicherung nur mit einer Sicherung gleichen Typs und den gleichen
Nennwerten.
ATTENTION: Pour ne pas compromettre la protection contre les risques
d’incendie, remplacer par un fusible de même type et de mêmes
caractéristiques nominales.
External Monitors
Windows 7 Ion Classic can support up to 2 monitors, either 2 DVImonitors or 1 Display Port
and 1 DVI.
Display Port can use an active adapter to VGA, DVI, or HDMI. DVI-I can be converted to VGA
with a passive adapter.
Monitor Specifications
Windows 10 consoles
•
Display resolutions of 1920x1080 (minimum) to 3480x2160 (maximum) are supported
•
Each display may be utilized in landscape or portrait mode
•
Multi-touch display support requires the following:
•
Data connection via USB-A or USB-C cable per multi-touch monitor
•
Windows Human Interface Device (HID) compliant touch displays, utilizing Windows
standard driver
•
Displays must process five or more points of simultaneous touch
•
Display Data Channel / Control Interface (DDC/CI) is supported for control of external
monitor brightness
•
Windows 7 consoles
•
Output to 4K resolution monitors my affect performance.
For monitor configuration, see {Monitor Arrangement...} (on page550) .
