ETC Source 4WRD II - Product Specifications; Electrical Specifications; Environment Specifications; Weight Specifications

Source 4WRD II Installation and User Manual 5
Specifications
For full product specifications, see the Source 4WRDII LED datasheet at
etcconnect.com.
Electrical
•
209–252 VAC 47–53 Hz power input
•
175 W draw at full
•
Recommended 2 fixtures per dimmed circuit (ED15 module)
•
Maximum of 6 fixtures per non-dimmed circuit (ER15AFR module)
•
If using in DMX mode: Connect fixture to relay, constant power, or
dimmer with regulation off and parked at full
•
Inrush: 12 A (first half-cycle)
Typical Power Consumption
Mode Power Current
Idle:DMXMode 3.7W .05A
Idle: ACMode 0W 0 A
Full Intensity 175W .75A
Environment
•
Ambient operating temperature: 5°C–50°C (41°F–122°F)
•
Minimum storage temperature: 5°C (41°F)
•
Maximum recommended ambient operating temperature:Ta=50°C
(122°F)
•
Maximum anticipated external surface temperature: Tmax=63°C
(145°F) at Ta=50°C (122°F)
•
External Temperature (steady state achieved) at 25°C (77°F)
ambient: 38°C (100°F)
Weight
•
Source 4WRDII LED retrofit kit only: 1.69kg (3.73lb)
•
Source 4WRDII LED installed on 26° fixture with yoke: 5.48kg
(12.1lb)
Optical
Compatible with all ETCSource Four lens tubes.
