ETC Studio HD - Channel Assignments in Direct Mode; Plus7 Profile Options

1 Installation and User Interface 29
Tungsten and Daylight
Channel assignments in direct mode
Plus7 profile options
DMX
Profile
DMX
Channels
Channel
Assignments
Notes
Studio 3
1 - Intensity
Control of parameters is also enabled from the
luminaire's user interface. No console is required
2 - Strobe
3 - Fan Control
Direct
3
1 - Intensity
2 - Strobe
3 - Fan Control
Channel
Number
Series 1
Studio HD
Series 1
Lustr+
Series 2
Lustr
Series 2
Daylight HD
Series 2
Tungsten HD
1 Red Red Red Red Red
2 Red Orange White Lime (not used) Red Orange
3 Mint Amber Amber Mint Mint
4 Blue Green Green Blue Blue
5 Indigo Cyan Cyan Indigo Indigo
6 n/a Blue Blue Intensity Intensity
7 n/a Indigo Indigo Strobe Strobe
8 Intensity Intensity Intensity Fan Control Fan Control
9 Strobe Strobe Strobe (not used) (not used)
10 Fan Control Fan Control Fan Control (not used) (not used)
Channel
Number
Series 1
Studio HD
Series 1
Lustr+
Series 2
Lustr
Series 2
Daylight HD
Series 2
Tungsten HD
1 Hue (course) Hue (course) Hue (course) Intensity Intensity
2 Hue (fine) Hue (fine) Hue (fine) Color Temp Color Temp
3 Saturation Saturation Saturation Tint Tint
4 Intensity Intensity Intensity Strobe Strobe
5 Strobe Strobe Strobe Fan Control Fan Control
6 Fan Control Fan Control Fan Control n/a n/a
7 n/a n/a n/a
Plus7 Control
on/off
Plus7 Control
on/off
8
Plus7 Control
on/off
Plus7 Control
on/off
Plus7 Control
on/off
Red Red
9 Red Red Red Mint Red Orange
10 Red Orange White Lime Blue Mint
11 Mint Amber Amber Indigo Blue
12 Blue Green Green (not used) Indigo
13 Indigo Cyan Cyan (not used) (not used)
14 (not used) Blue Blue (not used) (not used)
15 (not used) Indigo Indigo (not used) (not used)
