ETC Studio HD - DMX Footprints and Channel Mapping; Lustr+, Series 2 Lustr, Studio HD, Series 2 Daylight HD, Series 2 Tungsten HD

30 Source Four LED Profile v1.7.0 User Manual
DMX Footprints and Channel Mapping
Daylight and Tungsten
Lustr+, Series 2 Lustr, Studio HD, Series 2 Daylight HD, Series 2 Tungsten HD
* When this feature is enabled.
Channel Control
1 Intensity
2
Strobe
*
3
Fan control
*
Channel HSI HSIC RGB Studio Direct
1 Hue Hue Red Intensity Color 1
2 Hue fine Hue fine Green Color temp Color 2
3 Saturation Saturation Blue Tint Color 3
4 Intensity Intensity N/A N/A Color 4
5 Strobe* Strobe* Strobe* Strobe* Color 5
6
Fan control
*
Fan control
*
Fan control
*
Fan control
*
Color 6
7 N/A Color temp N/A N/A Color 7
8
Plus7 on/off
*
Plus7 on/off
*
Plus7 on/off
*
Plus7 on/off
*
Intensity
9
Plus7 - (1)
*
Plus7 - (1)
*
Plus7 - (1)
*
Plus7 - (1)
*
Strobe
*
10
Plus7 - (2)
*
Plus7 - (2)
*
Plus7 - (2)
*
Plus7 - (2)
*
Fan control
*
11
Plus7 - (3)
*
Plus7 - (3)
*
Plus7 - (3)
*
Plus7 - (3)
*
N/A
12
Plus7 - (4)
*
Plus7 - (4)
*
Plus7 - (4)
*
Plus7 - (4)
*
N/A
13
Plus7 - (5)
*
Plus7 - (5)
*
Plus7 - (5)
*
Plus7 - (5)
*
N/A
14
Plus7 - (6)
*
Plus7 - (6)
*
Plus7 - (6)
*
Plus7 - (6)
*
N/A
15
Plus7 - (7)
*
Plus7 - (7)
*
Plus7 - (7)
*
Plus7 - (7)
*
N/A
