In the electric plan there are different fuses and fuse holders that have the following functions:
There are 12 fuses located in the fuse holder pos.17 and they have the following functions and features
POSITION 1 : 30 A fuse vacuum motor (STANDARD)
POSITION 2 : 5 A fuse control board and battery charger protection;
POSITION 3 : 30 A service supply protection fuse (transformers, function control board, etc);
POSITION 4 : 10 A fuse pump protection;
POSITION 5 : 3 A fuse flashing light protection;
POSITION 6 : 10 A fuse for the protection of the 24V transformer 1 output (drive motor temperature indicator
warning light, drive motor temperature alarm buzzer, reverse buzzer, drive system operation warning
light, flashing lights)
POSITION 7 : 5A reverse light protection fuse;
POSITION 8 : 10 A fuse for the protection of the 24V transformer 2 output (all lights, horn, headlight warning
lights, handbrake warning light, handbrake buzzer)
POSITION 9 : 30 A suction motor protection fuse;
POSITION 10 : 3 A lid actuator protection fuse;
POSITION 11 : 3 A drive motor cooling fan protection fuse;
POSITION 12 : 3 A battery-charger cooling fan protection fuse;
Fuse pos.24: 80 Ah fuse BRUSH MOTORS PROTECTION
ATTENTION:This fuse is used by the function card to control the correct absorption of brush motors
(amperometric protection). It is possible that, although the motor reducers work with a correct absorption, error E1
appears on the display.
In this case there is an oxidation of the fuse that gives a wrong reading.
Please proceed as follows:
- Unscrew the 2 nuts pos.25 that fix the fuse of 80 Ah pos. 24
- Clean the fuse holder and oil it with vaseline
- Reassemble the nuts.
IMPORTANT: use exclusively the spare fuse by Eureka
Fuse pos.27: 125 A fuse PROTECTION OF THE DRIVE SYSTEM
TO REPLACE IT PROCEED AS FOLLOWS:
Remove the 2 nuts pos.26;
Replace 125 A fuse pos.27 with a fuse of equal amperage and with the same manufacturing characteristics;
Reassemble the 2 nuts.
Fuse pos.21: 20 A fuse CONTROL BOARD CARD PROTECTION;
TO CHECK OR REPLACE IT, PROCEES AS FOLLOWS:
Use a 2.5mm Allen wrench and remove the 10 clamping screws (see position 23) from the instrument panel, including
the respective nylon washers;
Carefully turn the instrument panel (see position 22), follow the arrows and make sure not to jerk it as it may damage
the electrical system;
Remove the 20 A fuse (see position 21), check it and replace it if necessary with a fuse of equal amperage;
Put the instrument panel back into place (see position 22);
Put the washer and screws back into place (see position 23) and close the panel using the special wrench, make sure to
apply enough pressure on the seal beneath the panel (see position 20).
Once the fuses are checked or replaced, put everything back together and bring the machine back to its operating
condition
