Eureka E110 - Cleaning, Replacing and Checking the Installation of the Squeegee Blades

31
CLEANING THE SQUEEGEE
1
2
2
5
4
3
After completing the washing operation, clean the squeegee and make sure the blades are in good condition, then proceed
as follows:
Deactivate the suction function, in case it is active and
lift the squeegee
Bring the machine into a stop position in a flat surface
area;
Turn the key to position 0 and put on the brake
Unscrew both screw knobs (see position 2 and remove the squeegee vacuum pipe (see position 1);
Remove the squeegee, lay it on the ground facing up (as shown in the figure), wash it using water and for better
vacuum flow, remove any pieces or incrustations from the lower part and from the mouth of the squeegee (see position
5);
Use a piece of cloth to wipe off the rear drying blade (see position 4) and the front drying blade (see position 3).
Make sure the blades are in good condition and rotate them if necessary in order to have a new edge in contact with
the floor.
