Eureka E110 - Trouble-Shooting Chart

53
IMPORTANT! ALL MAINTENANCE JOBS OR TESTS, WITH THE EXCEPTION OF THOSE DESCRIBED IN THE MANUAL,
MUST ONLY BE PERFORMED BY AN AUTHORISED AFTER-SALES CENTRE (AAC)
PROBLEM
CAUSE
SOLUTION
The battery gets discharged
1. Either exhaust or broken elements
Replace it
The display of the control card does not
switch on when inserting the key
2. Flat or worn out battery
3. 5A fuse burn out (pos. 2 fuses box)
4. 30A fuse burn out (pos.3 fuses box)
5. Services supply remote switch faulty
6. Emergency switch pressed
7. Battery mobile connector disconnected
8. Key operated switch broken
9. Control board is broken
Recharge it
Replace it
Replace it
Replace it
Unblock it
Connect it
Replace it
Replace it
When you press the brush button the
brush plate can not be lowered
10. Flat or worn out battery
11. Faulty actuator
12. Faulty card
13. Actuator control module on the control board is
broken
14. Some material got entangled underneath the brush
plate thus preventing it from lowering
15. Empty tank. The water output pipe lights are
flashing
16. Faulty floating device
Recharge it
Replace it
Replace it
Replace it
Remove the material as to unlock the brush plate
Fill the tank
Replace it
The brush motor does not rotate
17. Flat or worn out battery
18. Electric remote switch is broken
19. Control board is broken.
20. Amperometric protection cut-out switch of the
motor reducers
THE WRITING “E1” APPEARS ON THE
CONTROL BOARD
21. The thermal drill of the brush motor reducers
intervenes
22. Carbons are worn out
23. 80A Fuse burn out
24. Faulty engine
Recharge it
Replace it
Replace it
Turn the machine off and start it again by the
key, reactivate the cut-out switch. Check that
there aren’t any threads or any other material
which might get tangled with the brush
Wait until the machine gets cool and start it
again. Check that there aren’t any threads or any
other material which might get tangled with the
brush
Replace it
Replace it
Replace it
The drive does not work
25. Brake is engaged
26. Flat or worn out battery
27. Seat safety device engaged
28. Key disconnected
29. 125A protection traction fuse is faulty
30. Wheel gear motor is faulty
31. Wheel motor is broken or blocked
32. Motor carbons are worn out
33. Faulty electric motor remote switch
34. Electronic control board is broken
35. Faulty pedal box
36. Faulty pedal control
Disengage it
Recharge it
Sit down
Insert it
Replace it
Repair/replace it
Repair/replace it
Replace it
Replace it
Replace it
Repair/replace it
Repair/replace it
RED LIGHT on the control board; the
alarm enters into function and the gear
motor comes to a stop.
37. The temperature on the forward gear motor
exceeds 75-85° C.
38. Faulty relay
Wait till the temperature falls down before re-
starting the machine- Check the reason of the
over-heating (climbs, over absorption etc.) Clean
the motor air inlets.
Replace it
By pushing the brake pedal, the machine
does not stop
39. Blocked pedal
40. Blocked clamps
41. Worn clamps
42. Broken steel rope
Check it
Replace it
Replace it
Replace it
TROUBLE-SHOOTING CHART
