TRANSPORTING THE MACHINE BY MANUAL PUSHING
The machine is equipped with an electromagnetic brake
(pos. 1) that keeps the machine braked when off or when
the drive pedal is not pushed.
When moving the machine manually, the brake must be
disengaged by pulling the lever (pos. 2) into the position
indicated by the arrow and by keeping it in said position
while moving the machine.
Move the machine at a walking pace, do not tow it with
fork lifts.
Make sure that all the parts indicated in the following list are present before unpacking the machine:
• squeegee;
• batteries, cables fitted with connectors, terminals and terminal covers;
NOTICE: brushes, discs and disc pad holders must be purchased separately.
Follow the instructions below to unpack the machine:
- Connect the inclined ramp to the front part of the pallet, as shown in the figure;
- Remove the fasteners fixing the front wheels and any other devices;
- Disengage the electric brake on the front wheel as explained above;
- Make use of the inclined ramp.
CAUTION: DO NOT USE A FORKLIFT TO REMOVE THE MACHINE FROM THE PALLET AS IT MAY
CAUSE DAMAGE TO THE MACHINE.
