Eureka E75/2 - Detergent Solution Filter Cleaning

31
REPLACING THE SPLASH GUARD BLADES
Follow the instructions below to replace the side blades of the splash guard:
• Lift the brush plate and turn off the switch on the control panel;
• Turn off the machine and remove the key.
4
REPLACING THE SIDE BLADES
• Use a 4mm hex wrench (pos. 1) to
remove the screws;
• Remove the internal blade locking
plate (pos. 2);
• Remove the blade pos. 3 or pos. 4
with a new one;
• Put the rubber and the internal plate
back into place using the screws (pos.
1). Make sure that the rubber is
equally distributed throughout its
entire length.
CLEANING THE DETERGENT SOLUTION FILTER
1
2
3
4
The machine is fitted with a filter on the
duct coming from the detergent solution
tank.
In theory, the solution in the tank should
be free of impurities as the buckets or
containers used to fill the solution must to
be clean. Follow the instructions below to
clean the filter:
Stop the machine in a levelled area, turn
off the machine and remove the key;
• Close the valve using the lever (pos.
1);
• Use two hands to remove the clear cup
(pos. 2);
• Remove the protective screen (pos. 3)
and wash the cup and the screen with
water;
• Put the cup (pos. 2) and the protective
screen (pos. 3) on the fixed part of the
filter (pos. 4), making sure that the
protective screen is fitted correctly into
its housing on the cup and in the
support;
• Open the valve using the lever (pos. 1).
