Our scrubber-dryers must be operated by properly trained authorised staff.
Scrubber-dryers that do not operate properly must be taken out of service immediately.
Make sure to check the following before using the machine:
Make sure the battery connector is plugged-in;
Make sure the key is fitted correctly;
Check the battery charge level.
The charge level of the battery will appear in the
instrument panel when the machine is on. Charge the
batteries if the battery charging level is low.
Make sure the brushes or discs are in good condition
and mounted correctly.
Make sure the splash guards that are mounted into the
brush plate are in good condition.
Make sure the rubber wheels on the squeegee are in
good condition and set properly
Release the parking brake using the lever;
Turn the key to position 1;
Push the ON/OFF button. A green led will turn on and all the functions will be activated. At this
point, both the brush tray and the squeegee will lower. The brush motors and the vacuum motor
will switch by pressing the advance pedal. The quantity of detergent solution will be the one
wich has been kept in memory since the last time the machine has been used. In case you wish to
adjust it, work on the + and – buttons -on the control panel.
The brush function can be enabled individually using this button on the instrument panel. The
brush plate will lower onto the floor by means of the actuator; however, the brushes will not start
rotating until the drive command is activated.
Press the button again to disable the function and the pilot light will start flashing giving enough
time to lift the brush plate and switch off the motors before turning off itself.
If during the washing operation the led light of the brush bottom starts flashing, this means that there
is an over-absorption of the motors. After 1 minute with the flashing led light, the writing E1
appears on the control board. The brushes will stop lifting the plate
∙ When using the machine on particularly dirty surfaces, it is possible to have a further “extra-
pressure” on the brush plate. This function can be activated by pressing the special button, and only
if the brush function is already active. Switch it off to disable extra-pressure and resume normal
working conditions. By pressing the brush button when working on extra-pressure mode, you will
cause the brushes to stop rotating and the brush plate to automatically rise. If during the washing
operation the led light of the extra-pressure bottom starts flashing, this means that there is an over-
absorption of the motors. After 1 minute with the flashing led light, the extra-pressure function will
be deactivated automatically and you will continue working with the normal pressure.
It is possible to turn on the suction fan using the special button in the instrumental panel.
The squeegee will lower by means of the actuator; however, the suction fan will only come on
when the drive pedal is pressed.Press the button again to disable the function and the pilot light
will start flashing; the squeegee will remain on the floor for a preset period of time and it will
then lift and switch off the suction fan as well as the pilot light on the instrument panel.
The pilot light will also start to flash if the machine goes in reverse drive to indicate that the
squeegee is being raised from the floor. The machine is also fitted with a float that shuts off the
vacuum motor when the water level in the recovery tank is too high. If this occurs, the pilot light
on the suction motor button will start to flash and switch off the suction fan. The pilot light will
continue to flash until the tank is emptied, or until the machine switches off.
Drain the tank into the special drainage areas.
