1. Left control panel (control card)
2. Right control panel
3. Battery mobile connector
4. Ond-board battery charger display
5. Front wheel
6. Forward/reverse movement pedal
7. Anticapsizing device
8. Front anchor point
9. Drive control card
10. Splashguard
11. Brush motor
12. Rear anchor point
13. Battery charger cable
14. Seat adjusting lever
15. 250 diameter lid for inspection of the solution tank
16. ECO-SYSTEM floating device
17. Max. level floating device of the recovery tank
18. Flashing light
19. Vacuum motor discharge pipe
20. Recovery tank blocking lever
21. Battery
22. Hood and seat opening device
23. Seat
