Eureka E85 - CLEANING THE SOLUTION PIPE FITTING

30
CLEANING THE SOLUTION PIPE FITTING
The machine is fitted with a metering pump for detergent solutions.
If the solution does not flow out of the tank properly, make sure the output pipe fitting is not obstructed or clogged.
To check that proceed as follows:
 Bring the machine into a stop position in a flat surface area and put on the brake;
 Lower the brush plate pos.3 by pressing the special button in the control board;
 With the lowered plate, turn off the machine and remove the key;
 Unplug the mobile connector pos.4 from the fixed connector on the machine in order to remove the current.
 Unscrew the cap manually pos. 2;
 Use a thin piece of wire of aproximately Ø2-3 mm and remove any incrustations from the pipe fitting (position 1);
 Mount the cap pos.2;
 Connect the mobile connector pos.4 to the fixed connector;
 Insert the key and turn it towards the ignition;
 After some seconds, the machine will lift automatically the plate and it will be ready to start working.
